Product Description
Busbar machine for copper and aluminum bus bar machine
Product Name: JPMX-303CM Copper Sheet metal Switch board bus bar bender
Work Unite:
Bending cutting punching independently .
Metal Processed on :
Brass/Copper and Alumimum Busbar.
Applicaton Area:
Switch cabinet, electric control panel manufacturing , high low voltage switchgear, eletric transformer station,
Bending cutting punching independently .
Metal Processed on :
Brass/Copper and Alumimum Busbar.
Applicaton Area:
Switch cabinet, electric control panel manufacturing , high low voltage switchgear, eletric transformer station,
Electric panel ,voltage transformer,appliance swich,ship manufacturing,electric elevator manufacturing,electric
cabinet manufacturing , Power distribution system product maufacturing.
Functions:
1. bending at vertical and horizontal direction.
2. punching for round and oblong hole.
3. cutting busbar.
4. special for embossing, knurling, twisting, cable joints pressing.
Main characteristics:
1. The shearing unit use sharp shearing, the incision interface is flat, no droop and burrs and waste.
2. The unit uses a closed structure to make sure the flat bending and embossing more smooth, which highly
Functions:
1. bending at vertical and horizontal direction.
2. punching for round and oblong hole.
3. cutting busbar.
4. special for embossing, knurling, twisting, cable joints pressing.
Main characteristics:
1. The shearing unit use sharp shearing, the incision interface is flat, no droop and burrs and waste.
2. The unit uses a closed structure to make sure the flat bending and embossing more smooth, which highly
improve the repearing precision duting mass production and prolong the working time. The bending unit is a
horizontal type and it is very easy to operate.
3. DM,CM series allow that three working positions can do their only operation at same time without interfere
3. DM,CM series allow that three working positions can do their only operation at same time without interfere
the others. Working efficiency will be highly improved.
4. The machine has four casters, so it is easily to be moved everywhere. There are two operating modes,
4. The machine has four casters, so it is easily to be moved everywhere. There are two operating modes,
manual button and foot switch button, which is easily for worker to operate and use. Based on users requirement,it can do all kinds of special shape processing with different molds or equipping parts.
Technical Parameters:
Function
|
Item
|
Model
| ||
JPMX-303CM
|
JPMX-303DM
|
JPMX-503DM
| ||
Punching
|
Max. Punching Force (KN)
|
300
|
300
|
500
|
Punching Diameter Range (MM)
|
4.3-25
|
4.3-25
|
4.3-34
| |
Max. Thickness (MM)
|
12
|
12
|
16
| |
Max. Width (MM)
|
160
|
160
|
200
| |
Shearing/Cutting
|
Max. Shearing Thickness (MM)
|
12
|
12
|
16
|
Max. Shearing Width (MM)
|
160
|
160
|
200
| |
Vertical Bending
|
Max. Bending Force (KN)
|
300
|
300
|
500
|
Max. Width (MM)
|
160
|
160
|
200
| |
Max. Thickness (MM)
|
12
|
12
|
16
| |
Honrizental Bending
|
Max. Width (MM)
|
100(10mm THK)
|
100(10mm THK)
|
120(10mm THK)
|
Max. Angle (Degree)
|
90°
|
90°
|
90°
| |
Out Dimension
|
MM
|
1500*1300*1200
|
1550*1300*1200
|
1800*1500*1200
|
Power
|
KW
|
1*4KW
|
3*4KW
|
3*5.5KW
|
Weight
|
KG
|
1150KG
|
1250KG
|
1850KG
|
Configuration Checklist:
8 sets of punching die. (Ø7, Ø9, Ø11, Ø13, Ø15, Ø17, Ø13 * 18, Ø17 * 21 or as per customer's requirement)
1 set of shearing die
2 sets of horizontal bending die
2 sets of vertical bending die
2 sets of vertical bending die
1 set of embossing die
1 set of U bending die
1 set of oil filler
1 set of tool for die installing
3 sets of foot switches
1 set of hydraulic system sealing ring
2 pieces of Limit Switch
1 piece punching location pin.
1 set of tool for die installing
3 sets of foot switches
1 set of hydraulic system sealing ring
2 pieces of Limit Switch
1 piece punching location pin.
Packaging & Shipping
The Packing of Busbar bending machine is plywood case .
Functional show
Our Services
Our advantage:
1. Warranty : one year guarantee for whole busbar machine ( not including spare part)
2. Our thermal relays, AC contactors, circuit breakers are from Schneider.
3. We are factory. we can do OEM as per clients request.
4. We have strong after-sales services team and professional technicians who can gurantee
professional guidance after sales.
5. With Certification of CE&ISO 9001 .
Schneider Thermal Relay, AC contactor, circuit breaker
Exhibition
Jinan Jingpeng CNC Machinery have taken part in many exhibitions for Busbar machine in China and worldwide.
JingPeng Care For Your Switchgears
Company Information
Jinan Jingpeng CNC Machinery Co., Ltd. is a technology company, specializing in the developing, production, selling of electrical & CNC metal plate machines. We have much advanced management experience, strong technology and large selling networks.
FAQ
1. What is your payment terms:
30% TT as deposit, balance be paid when goods are ready for loading before shipment.
2. What is your delivery time?
Usually within 7-20 days after the deposit.
3. What is your power supply?
We will adjust according to your countries power supply. No problem.
4. What is the language of the manual and instructions on machine ?
All in English language .
5. What is your Min order quantity?
One set. Our customers can be end users, retailers and wholesalers.
Any questions, please don't hesitate to contact me.
